Speaking the sacred phrase

Reversing the WeeperVM crackme without a debugger

31 August 2026 · 8 min read

After I revived the blog I said I want to write about the stuff I encounter. So here is the first real one.

On crackmes.one I picked WeeperVM - Level 1 by Ben_Lolo. It’s rated very hard (5.0) and the description promised a lot:

• Encrypted strings
• Anti-debug
• Anti-breakpoint
• Anti-thread suspension
• Anti-patch
• Virtualized code with loops, if/else, and janky functions

A whole VM plus five anti-analysis tricks. Sounded like a nice evening. It was more than one evening.

The goal is simple: give the program the right sacred phrase and it lets you in. Everything below was done static, with radare2, objdump and a bit of gdb, plus a small Python model of the VM. No patching, no debugger on the real run, and you will see why.

• First look
• The protections
  • Encrypted strings
  • Anti-debug
  • Anti-patch / anti-breakpoint
  • Anti-thread-suspension
• The VM core
• Writing the emulator
• The check
• The cipher
• Inverting it
• Result
• Conclusion

First look

$ rabin2 -I WeeperVM--Level_1
arch     x86      bits 64      class ELF64      pic true      stripped true
$ rabin2 -S WeeperVM--Level_1
...
10  0x00010a00  0x119f  0x00010a00  ...  -r-x  .text
14  0x00001f60  0xcd4   0x00011f60  ...  -r--  .weep       <-- custom
20  0x00002f20  0x100   0x00012f20  ...  -rw-  .lotus      <-- custom
21  ----------  ----    0x000130c0  0xa0 -rw-  .bss

Two sections that no compiler puts there. Running it:

$ ./WeeperVM--Level_1
 /\\\______________/\\\__/\\\...           (a big "WEEPER" ascii banner)
Long time no see, friend.
Let us speak the sacred phrase:
Have you forgotten it :(

Whatever I typed, Have you forgotten it :(. The imports of interest are already telling a story: fopen/fread/fseek/ftell (self-inspection), pthread_create/join, syscall, time, sleep, strstr, __isoc99_sscanf, atoi. Classic anti-debug plumbing.

.lotus begins with a base64 looking alphabet, which is a strong hint that the rest of the file is VM material:

$ objdump -s -j .lotus WeeperVM--Level_1
 12f20 41424344 45464748 ...  ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789()
 12f60 d4cecc6d 66a4a697 ...  <s-box / tables / key material / message glyphs>

So .lotus is 256 bytes of data memory and .weep is code for some machine. A VM. The description did say so.

The protections

Before touching the VM I wanted to know what fires when. Short version, there are five things and all of them only hurt you if you run it wrong.

Encrypted strings

fcn.10e27 is a repeating XOR, out[i] = ct[i] ^ key[i % klen]. The ct and key pointers are inline immediates.

;-- fcn.10e27 (char *ct, int len, char *key, int klen):
0x00010e45  call calloc(len+1, 1)
0x00010e56  idiv ebp                   ; ecx % klen
0x00010e5b  mov  al, [r13 + rdx]       ; key[i % klen]
0x00010e60  xor  al, [r12 + rcx]       ; ^ ct[i]
0x00010e64  mov  [rsi + rcx], al

Recovering every call gives:

/proc/self/maps      /proc/self/mem       /proc/self/exe
/proc/self/status    TracerPid:           r-xp     %lx-%lx
"Were my bytes not good enough for you >:("
"How dare you... I worked hard on those threads >:("
"Sumin' ain't right..."         "How 'bout no???"

Nothing secret, just hidden from strings.

Anti-debug

fcn.11133 opens /proc/self/status, strstr for TracerPid:, atoi the number behind it. Not zero means a debugger is attached, return non-zero, and a watchdog thread kills the run.

Anti-patch / anti-breakpoint

fcn.10fe7 reads /proc/self/exe into a buffer and hashes it, then compares against an 8 byte value at the end of the file.

0x00011029  call fopen("/proc/self/exe","rb")
0x0001108c  call fread(buf, 1, filesize, f)
0x0001109e  mov  ebx, 0x102a           ; h = 0x102a
0x000110b3  imul rbx, rbx, 0x11        ; h = h*0x11 + byte      (djb2-ish)
0x000110bf  add  rbx, rcx
...
0x000110f1  cmp  rbx, r13              ; vs the 8-byte trailer
0x000110f4  sete al

fcn.10af6 does the same again, but parses /proc/self/maps, finds the r-xp mapping and hashes that address range straight out of /proc/self/mem. So a single 0xCC breakpoint or one patched byte in .text changes the hash and it aborts.

Anti-thread-suspension

fcn.110ff is called on every VM step and inside READ.

0x00011109  call time(NULL)
0x00011117  mov  rax, [rbp + rdx*8]    ; watchdog struct
0x00011122  sub  rsi, [rax]            ; now - last_heartbeat
0x00011125  cmp  rsi, 2                ; > 2s  -> return non-zero

The two watchdog threads (fcn.1120d, fcn.10cba) just loop { heartbeat = time(); sleep(1); re-run the two checks above }. Freeze a thread in a debugger and that delta blows past 2s.

Add it all up and the answer is boring: don’t attach a debugger, don’t patch a byte. Reverse the VM on paper and rebuild the check in an emulator, then none of this machinery ever runs. I still single stepped the interpreter itself in gdb once to confirm the decode, that part has no checks around it.

The VM core

main (0x11a9b) is small once you ignore the watchdog setup. It is a fetch/execute loop over .weep, an array of 32 bit words, and a 0 word means halt, which is also the success case.

;-- main:
0x00011aa0  call fcn.00011266          ; spin up watchdog thread #1  (fcn.1120d)
0x00011aa8  jne  0x11ac0               ; NULL -> "Sumin' ain't right..."
0x00011ac5  call fcn.00010d2e          ; spin up watchdog thread #2  (fcn.10cba)
0x00011ad0  jne  0x11aff               ; NULL -> "How dare you... threads >:("
0x00011b03  mov  qword [0x13050], rax  ; watchdog #1 timestamp slot
0x00011b0e  mov  qword [0x13058], rax  ; watchdog #2 timestamp slot
0x00011b17  call fcn.00010fe7          ; anti-patch: hash live .text vs trailer
0x00011b1e  jne  0x11b36               ; mismatch -> "Were my bytes not good enough >:("
0x00011b3b  mov  edi, 0x13050
0x00011b40  call fcn.000110ff          ; anti-thread-freeze: watchdog timestamp check
0x00011b4d  je   0x11b76               ; ok -> enter the VM
                                       ; --- VM fetch/execute loop ---
0x00011b65  call fcn.00011a28          ; step: execute .weep[PC]
0x00011b6c  jne  0x11af5               ; step returned != 0 -> generic error, exit 1
0x00011b6e  mov  eax, [0x13040]        ; PC
0x00011b74  inc  eax
0x00011b76  mov  [0x13040], eax        ; PC++
0x00011b7e  mov  edi, [rax*4 + 0x11f60]; instr = .weep[PC]
0x00011b87  jne  0x11b65               ; instr != 0 -> keep going
0x00011b89  ... fcn.112e9 / fcn.10dbc  ; stop + join watchdog threads
0x00011b9e  ret                        ; instr == 0 (HALT) -> success

The step function fcn.11a28 decodes one word W. Every word is stored xored with a broadcast of its own byte 2:

0x00011a35  call fcn.000110ff          ; heartbeat check first
0x00011a3f  mov  eax, ebx              ; eax = instruction word W
0x00011a41  shr  eax, 0x10
0x00011a44  movzx eax, al              ; b2 = (W >> 16) & 0xff
0x00011a47  imul eax, eax, 0x1010101   ; b2 * 0x01010101
0x00011a4d  xor  eax, ebx              ; D = W ^ (b2*0x01010101)   -> byte2(D) == 0
0x00011a56  movzx edx, ah              ; Dop = byte1(D)
0x00011a59  shr  ecx, 0x19             ; C  = (D >> 25) & 3
0x00011a5c  shr  esi, 0x1b             ; S  = (D >> 27) & 1
0x00011a5f  movzx r8d, al              ; R8 = byte0(D)
0x00011a69  shr  edi, 0x1c             ; OP = D >> 28
0x00011a6c  jmp  0x119c0
;-- 0x119c0: shuffle regs, then dispatch
0x000119cb  cmp eax, 0xf
0x000119ce  ja  0x11a22                ; OP > 15 -> abort
0x000119d0  jmp qword [rax*8 + 0x11e68]; opcode jump table (16 entries)

Byte 2 of D is always zero afterwards, so it is a cheap tamper check, flip a code byte and the decode goes wrong. The fields:

State is mem (the 256 bytes of .lotus), a register file at 0x13080 (reg[i] = dword [0x13080 + i*4]), the flags byte at 0x13060 and the PC at 0x13040. Walking the 16 handlers off the jump table at 0x11e68:

reg[14] and reg[15] are only ever scratch jump targets, every MOV r14,#255 ; ADD r14,#k cluster in the bytecode is just computing a branch address for the next JMPC.

Writing the emulator

With the decode and the handlers known I wrote a disassembler (weep_dis.py) and an emulator (weep_emu.py). The decode is the whole trick:

OPS = {0:"MOV",1:"MOVI",2:"ADD",3:"SUB",4:"MUL",5:"MOD",6:"PRINT",7:"READ",
       8:"BAD",9:"CMP",10:"JMPC",11:"AND",12:"OR",13:"XOR",14:"SHL",15:"SHR"}

def decode(w):
    b2 = (w >> 16) & 0xFF
    key = (b2 * 0x01010101) & 0xFFFFFFFF
    d = w ^ key
    op  = (d >> 28) & 0xF
    s   = (d >> 27) & 1
    c   = (d >> 25) & 3
    dop = (d >> 8) & 0xFF
    r8  = d & 0xFF
    return op, s, c, dop, r8, d

The emulator is just that plus the 16 handlers. mem is the raw .lotus section, reg is 256 zeros, flags starts at 0, pc indexes the word array:

def run(self, max_steps=5_000_000):
    while self.steps < max_steps:
        w = self.words[self.pc]
        if w == 0:
            return "HALT"
        b2 = (w >> 16) & 0xFF
        d = w ^ ((b2 * 0x01010101) & MASK)
        OP = (d >> 28) & 0xF
        S  = (d >> 27) & 1
        C  = (d >> 25) & 3
        Dop = (d >> 8) & 0xFF
        R8 = d & 0xFF
        self.steps += 1
        jt = self.exec(OP, S, C, Dop, R8)
        if jt is not None:
            self.pc = jt
        else:
            self.pc += 1
    return "MAXSTEPS"

def exec(self, OP, S, C, Dop, R8):
    m, r = self.mem, self.reg
    if OP == 0:    # MOV
        self.dst_set(S, Dop, self.src_val(C, R8))
    elif OP == 1:  # indirect load / store
        v = self.src_val(C, R8)
        if S == 0:
            r[Dop] = m[v & 0xFF]
        else:
            m[m[Dop] & 0xFF] = v & 0xFF
    elif OP == 2:  self.dst_set(S, Dop, self.dst_get(S, Dop) + self.src_val(C, R8))
    elif OP == 3:  self.dst_set(S, Dop, self.dst_get(S, Dop) - self.src_val(C, R8))
    elif OP == 4:  self.dst_set(S, Dop, self.dst_get(S, Dop) * self.src_val(C, R8))
    elif OP == 5:
        s = self.src_val(C, R8)
        self.dst_set(S, Dop, (self.dst_get(S, Dop) % s) if s else 0)
    elif OP == 6:  # PRINT
        ch = (r[Dop] & 0xFF) if S == 0 else m[Dop]
        self.out += bytes([ch]) * self.src_val(C, R8)
    elif OP == 7:  # READ
        n = self.src_val(C, R8)
        i = 0
        while i < n:
            if self.inpos >= len(self.inbuf):
                break
            ch = self.inbuf[self.inpos]; self.inpos += 1
            if ch == 0x0A:
                break
            m[(Dop + i) & 0xFF] = ch
            i += 1
        else:
            # filled all n bytes without a newline: the handler does one more read,
            # only a lone '\n' is accepted, anything else sets the "too long" flag 0x20
            rest = self.inbuf[self.inpos:self.inpos+64]
            self.inpos += len(rest)
            if rest != b"\n":
                self.flags |= 0x20
    elif OP == 8:
        return -1  # invalid -> abort
    elif OP == 9:  # CMP
        dst = (r[Dop] & MASK) if S == 0 else m[Dop]
        src = self.src_val(C, R8)
        base = 0x60 if (self.flags & 0x20) else 0x40
        if dst == src:   self.flags = base | 1
        elif src > dst:  self.flags = base | 4
        else:            self.flags = base | 2
    elif OP == 10:  # JMPC
        mask = self.src_val(C, R8)
        target = (r[Dop] & MASK) if S == 0 else m[Dop]
        if self.flags & mask:
            return target
    elif OP == 11: self.dst_set(S, Dop, self.dst_get(S, Dop) & self.src_val(C, R8))
    elif OP == 12: self.dst_set(S, Dop, self.dst_get(S, Dop) | self.src_val(C, R8))
    elif OP == 13: self.dst_set(S, Dop, self.dst_get(S, Dop) ^ self.src_val(C, R8))
    elif OP == 14: self.dst_set(S, Dop, self.dst_get(S, Dop) << (self.src_val(C, R8) & 31))
    elif OP == 15: self.dst_set(S, Dop, (self.dst_get(S, Dop) & MASK) >> (self.src_val(C, R8) & 31))
    return None

The src_val / dst_get / dst_set helpers just fold the S and C bits:

def src_val(self, C, R8):
    if C == 0: return self.reg[R8] & MASK
    if C == 1: return self.mem[R8]
    if C == 2: return R8

def dst_get(self, S, Dop):
    return (self.reg[Dop] & MASK) if S == 0 else self.rd_dword(Dop)

def dst_set(self, S, Dop, val):
    if S == 0: self.reg[Dop] = val & MASK
    else:      self.wr_dword(Dop, val)

Run it with an empty stdin and it prints the same banner and the same intro lines as the real binary, byte for byte. So the model is right.

The check

The interesting bytecode starts at instruction 358. Disassembled:

 358: MOV   reg[4], #32
 359: READ  mem[64], maxlen=reg[4]        ; read the phrase into mem[64..95]
 361: MOV   reg[12], #0
 362: MOV   reg[14], #255                 ; reg[14] = 255 + 135 = 390  (fail target)
 363: ADD   reg[14], #135
 ...
 368: MOV   reg[6], #64
 369: ADD   reg[6], reg[12]
 370: LOAD  reg[5] = mem[reg[6]]          ; c = phrase[i]
 371: CMP   reg[5], mem[62]               ; '('  -> ok
 372: JMPC  PC=reg[14]  if flags & #1
 373: CMP   reg[5], mem[63]               ; ')'  -> ok
 374: JMPC  PC=reg[14]  if flags & #1
 375: CMP   reg[5], mem[254]              ; '_'  -> ok
 376: JMPC  PC=reg[14]  if flags & #1
 377: MOV   reg[2], mem[51]               ; 'z'
 378: SUB   reg[2], reg[5]
 379: CMP   reg[2], #26                   ; 'z'-c < 26  -> 'a'..'z'
 380: JMPC  PC=reg[14]  if flags & #4
 381: MOV   reg[2], mem[25]               ; 'Z'
 382: SUB   reg[2], reg[5]
 383: CMP   reg[2], #26                   ; 'Z'-c < 26  -> 'A'..'Z'
 384: JMPC  PC=reg[14]  if flags & #4
 385: MOV   reg[2], mem[61]               ; '9'
 386: SUB   reg[2], reg[5]
 387: CMP   reg[2], #10                   ; '9'-c < 10  -> '0'..'9'
 388: JMPC  PC=reg[14]  if flags & #4
 389: JMPC  PC=reg[15]  if flags & #64    ; nothing matched -> fail

So the whole check is:

1. READ up to 32 bytes into mem[64..95]. The handler does one more read afterwards and only accepts a lone \n, so the phrase has to be exactly 32 chars, otherwise the 0x20 (“too long”) flag is set.
2. charset loop above: each byte must be a-z, A-Z, 0-9 or one of ( ) _.
3. round key init at instruction 398: mem[192+i] = mem[160+i] ^ mem[176+i] for i in 0..15.

 400: MOV   reg[12], #0
 401: MOV   reg[2], #160
 402: ADD   reg[2], reg[12]
 403: LOAD  reg[0] = mem[reg[2]]          ; mem[160+i]
 404: ADD   reg[2], #16
 405: LOAD  reg[1] = mem[reg[2]]          ; mem[176+i]
 406: ADD   reg[2], #16
 407: MOV   mem[240], reg[2]
 408: XOR   reg[0], reg[1]
 409: STORE mem[mem[240]] = reg[0]        ; mem[192+i] = mem[160+i] ^ mem[176+i]
 410: ADD   reg[12], #1
 411: CMP   reg[12], #16
 412: JMPC  PC=reg[14]  if flags & #4

1. the cipher (next section).
2. compare mem[64..95] byte for byte against 32 constants, read straight off the CMP #imm operands:

dc 6f 56 c2 d3 4e 50 77 69 b2 4d e9 8f f5 2d 12
2a 95 81 e5 35 db 8a 10 14 ff a7 04 d0 c1 e5 74

The CMP handler carries the “too long” bit into the flags byte, so a wrong-length input can never reach the win:

0x0001178b  mov  al, 0x40
0x0001178d  test byte [0x13060], 0x20   ; the "too long" bit
0x00011796  mov  al, 0x60
0x00011798  cmp  esi, ecx               ; esi = dst, ecx = src
0x0001179a  jne  0x117a1
0x0001179c  or   eax, 1                 ; equal   -> b0
0x117a1     or   eax, 2 / or edx, 4     ; dst>src -> b1 ; dst<src -> b2
0x000117ae  mov  byte [0x13060], al

Funny detail, the messages are swapped from what you expect. Falling through the whole comparison is the win and prints Welcome home :), any mismatch prints Have you forgotten it :(. If you only read the strings you get it the wrong way around.

The cipher

mem[64:96] is handled as two independent 16 byte blocks (mem[64:80], mem[80:96]). Each block is a byte-wise balanced Feistel: left half L is 8 bytes, right half R is 8 bytes, 16 iterations, and one iteration is:

for r in 0..7:                    # one sub-round per byte of R
    f = F(R[r], iteration, r)
    for k in 0..7:                # scatter the 8 bits of f into L
        j = (r + OFF[k]) % 8      # OFF = [7,6,2,1,5,0,3,4]
        L[j] ^= f & (0x80 >> k)
L, R = R, L                       # half swap

then one more half swap after the 16 iterations, and between block 0 and block 1 the 16 byte round key array mem[192:208] is rotated left by 7.

The round function F (bytecode 418..506) was the janky part:

def Fr(rbyte, rk_xor, test_bit):
    hi, lo = rbyte >> 4, rbyte & 0xF
    if test_bit == 0:                       # path A: S_HI:S_LO
        v = (S_HI[hi] << 4) | S_LO[lo]
    else:                                   # path B: S_LO:S_HI
        v = (S_LO[hi] << 4) | S_HI[lo]
    v ^= rk_xor                             # round key xor, both paths
    return P(v)                             # fixed bit permutation

with test_bit = KEY[(7*it) % 16] & (1 << r) and rk_xor = KEY[(7*it + r) % 16]. S_HI and S_LO are the high and low nibbles of the 16 byte s-box at mem[128:144], both are permutations of 0..15 so F is invertible. P is a fixed bit shuffle {7:4, 6:2, 5:7, 4:3, 3:5, 2:6, 1:0, 0:1}.

It looks scary but L is only ever touched as L[j] ^= something(R) and the halves swap every round. That is a textbook Feistel. It does not even matter that F is ugly, you never invert F, you just replay the rounds backwards.

Inverting it

weep_crack.py lifts the s-box, the bit permutation and the key material out of .lotus, reimplements the transform forward (checked bit for bit against the emulator on random inputs), then runs the 16 iterations backwards on the ciphertext, per block, block 1 with the key rotated left by 7. The inverse iteration is almost the same code as the forward one, because R is untouched by the sub-rounds so the F values are recomputable directly:

def feistel_iter_inv(half_L, half_R, it, key):
    Rh_after, Lh_after = list(half_L), list(half_R)
    Lh, Rh = Lh_after, Rh_after            # undo the swap
    for r in range(8):
        test = key[(7*it) % 16] & (1 << r)
        f = Fr(Rh[r], key[(7*it + r) % 16], test)
        for k in range(8):
            j = (r + OFF[k]) % 8
            Lh[j] ^= (f & (0x80 >> k))
    return Lh, Rh

$ python3 weep_crack.py
OK   in= b'ABCDEFGHIJKLMNOPQRSTUVWXYZabcd1'
OK   in= b'aaaaaaaaaaaaaaaaaaaaaaaaaaaaaa1'
OK   in= b'Th3_S3cr3t_Ph4s3_G0es_H3re_(x)1'

required mem[64:96] = 28297633 4e673334 6e63655f 49355f34 6e5f3144 31305435 5f67346d 335f2829
as text            = b'()v3Ng34nce_I5_4n_1D10T5_g4m3_()'

All 32 bytes land in [A-Za-z0-9()_] on their own, so the charset gate is happy and there is exactly one phrase that works (fixed ciphertext, bijective transform).

Result

$ printf '%s\n' '()v3Ng34nce_I5_4n_1D10T5_g4m3_()' | ./WeeperVM--Level_1
 ...
Let us speak the sacred phrase:
Welcome home :)

Read as english it is “(vengeance is an idiots game)” in leet. Make of that what you want.

Conclusion

This was hard, but the good kind of hard. The five protections sound intimidating on the crackme page and they are actually implemented properly, but the moment you decide to work static and rebuild the check offline they all turn into dead weight, none of them ever fires. Most of the time went into the VM decode and into getting the Feistel iteration order exactly right, off by one half swap and nothing matches.

Nice challenge. Thanks Ben_Lolo. Onto Level 2, I guess.
